Rogers Circuit Board Manufacturing
Rogers circuit board manufacturing with Rogers PCB material (RO4350B, RO4003C, RT/duroid 5880) for high frequency PCB RF, microwave and 5G applications.
What is a High Frequency PCB?
A High Frequency PCB is built with specialized low-loss dielectric materials designed for applications operating from MHz to GHz frequencies. Unlike standard FR-4, these materials maintain stable electrical properties at high speeds, ensuring minimal signal loss and excellent impedance control.
Rogers Series
RO4000/RO3000/RT/duroid, Dk 2.2–10.7
Full range of Rogers high-frequency laminates including RO4350B, RO4003C, RO3003, RT/duroid series. Ceramic-filled hydrocarbon and PTFE composites offering exceptional electrical stability for RF, microwave and mmWave applications up to 77+ GHz.
PTFE (Teflon)
Dk = 2.1–3.0, Df = 0.001–0.002
Ultra-low-loss PTFE-based materials for the most demanding high-frequency applications. Exceptional signal integrity at microwave and millimeter-wave frequencies with minimal dielectric absorption.
Panasonic / Nelco / Isola
Megtron 6/7, I-Speed, FR408HR
High-speed, low-loss laminates from leading suppliers for high-speed digital and RF hybrid applications. Mid-loss, low-loss, very-low-loss, and ultra-low-loss grades available.
Taconic / Other HF Materials
Hydrocarbon, PTFE composites
Taconic TSM/TLY series and other specialized high-frequency materials including PI, MPI, and LCP for flexible RF applications.
Key Benefits
Low Dielectric Loss
Minimized signal attenuation ensures maximum power transfer and efficiency in RF and high-speed digital circuits.
Stable Performance at High Speeds
Consistent dielectric constant across frequency and temperature ranges maintains impedance control and signal fidelity.
Excellent Signal Integrity
Low dissipation factor and tight Dk tolerance reduce reflections and crosstalk, critical for GHz-range applications.
Applications
High-frequency PCBs enable next-generation wireless and RF technology.
RF & Microwave Systems
Amplifiers, filters, antennas, and transceivers operating at microwave frequencies with stringent loss requirements.
5G Infrastructure
Base stations, beamforming antennas, and millimeter-wave modules that demand low-loss, high-frequency substrates.
Satellite Communication
Space-grade RF circuits, phased array antennas, and transponders requiring reliable performance in extreme environments.
Capabilities
Technical specifications for our high-frequency PCB manufacturing.
| Parameter | Value |
|---|---|
| Layer Count | 1 – 24 Layers |
| Board Thickness | 0.3 – 3.4 mm |
| Max Panel Size | 724 × 622 mm (28.5" × 24.5") |
| Min Line Width/Space (Inner) | 0.05 / 0.05 mm |
| Min Line Width/Space (Outer) | 0.05 / 0.05 mm |
| Line Width Tolerance | ±20% (Typical), ±10% (Advanced) |
| Controlled Impedance | ±8% |
| Min Mechanical Drill | ≥0.15 mm |
| Min Laser Drill | ≥0.075 mm |
| Max Aspect Ratio (PTH) | 12:1 |
| Max Aspect Ratio (Microvia) | 1:1 (HDI) |
| Layer to Layer Registration | 5 mil |
| Backdrill Depth Tolerance | ±3 mil |
| Signal Integrity Testing | SET2DIL / Delta-L / VNA |
| Hole-wall Copper | 20 – 70 μm |
| Finished Copper (Outer) | 1 – 5 oz |
| Surface Finish | ENIG, Immersion Silver, Immersion Tin, OSP, Gold Finger |
| HF Material Types | Hydrocarbon, PTFE, High-Speed (mid/low/very-low/ultra-low loss), PI, MPI, LCP |
Why Choose Lianyuhong?
Your trusted partner for high-frequency PCB manufacturing.
High-Frequency Performance
Specialized processing for Rogers and PTFE materials ensures precise dielectric control and minimal loss for your RF designs.
Reliable Quality Assurance
Every high-frequency PCB undergoes comprehensive electrical testing, impedance verification, and AOI inspection.
Competitive Pricing
Leverage our material sourcing and manufacturing efficiency for premium HF materials at competitive prices.
Fast Prototyping
Quick-turn high-frequency PCB prototypes with expert DFM review to accelerate your development cycle.
How to Order
Three simple steps to get your high-frequency PCBs.
Upload Files
Upload your Gerber files and specify high-frequency material requirements.
Get Quote
Receive an instant, transparent quote tailored to your HF material selection.
Receive Boards
Your high-frequency PCBs are fabricated, tested, and shipped to you.
Rogers PCB Materials We Support
As a Rogers circuit board manufacturer, we stock and process the full range of Rogers PCB material grades for RF, microwave and 5G designs.
| Material | Dielectric Constant | Dissipation Factor | Typical Application |
|---|---|---|---|
| RO4350B | 3.48 | 0.0031 | RF power amplifiers, base station antennas |
| RO4003C | 3.38 | 0.0027 | Cost-sensitive RF / microwave designs |
| RO4835 | 3.48 | 0.0033 | High-temperature RF / automotive radar |
| RT/duroid 5880 | 2.20 | 0.0009 | Millimeter-wave, aerospace antennas |
| RO3003 | 3.00 | 0.0013 | 5G mmWave, automotive radar |
| RO3010 | 10.2 | 0.0035 | Miniaturized high-Dk RF circuits |
Why Choose Rogers for High-Frequency Designs?
Low Dielectric Loss
Rogers laminates deliver ultra-low dissipation factors that minimize signal attenuation for efficient RF power transfer.
Controlled Impedance
Tight, stable dielectric constant across frequency and temperature enables precise impedance control for high-frequency signals.
CTE Matching
Rogers PCB material CTE is well-matched to copper and FR-4, improving plated through-hole reliability and hybrid multilayer builds.
Need high-density RF interconnects? Explore our HDI PCB capabilities. For RF prototype speed, see our quick-turn PCB assembly service.
Ready to Start Your Project?
Send us your design files and let our team provide a competitive quote within 24 hours.
