Professional PCB Layout Services
Expert schematic and PCB design services with DFM review and SI/PI simulation. From concept to production-ready files.
Our Design Services
End-to-end PCB design services from concept through manufacturing release.
Schematic Design
Complete schematic capture and design from concept to production-ready documentation with proper hierarchy and annotation.
PCB Layout
Multi-layer, HDI, and flexible PCB layout with optimal component placement, layer stacking, and routing strategies.
SI/PI Simulation
Signal integrity and power integrity analysis including SET2DIL, Delta-L, and VNA-based verification to ensure your design meets performance targets before fabrication.
DFM Review
Comprehensive Design for Manufacturing review to identify and resolve potential production issues early in the design cycle.
Impedance Control Design
Controlled impedance routing and stackup design for high-speed digital, RF, and sensitive analog applications.
Design Capabilities
Industry-leading design tools and technical specifications.
| Parameter | Specification |
|---|---|
| Design Software | Altium, KiCad, Eagle, Cadence, Mentor |
| Max Layers | Up to 24 layers (aligned with fab capability) |
| Min Track/Space | 0.04mm (flex) / 0.05mm (rigid) |
| Min Via Size | 0.075mm laser / 0.15mm mechanical |
| Impedance Accuracy | Controlled ±8% (with SI verification) |
| HDI Capability | Anylayer, 5+N+5, Blind/Buried Vias, Backdrill |
| Technologies | Rigid, Flex, Rigid-Flex, HDI, Metal Core (IMS), High-Frequency |
| High-Frequency Design | Rogers, PTFE, High-Speed materials stackup design |
| Max BGA Pitch | 0.35mm (HDI) / 1mm with backdrill |
| Output Formats | Gerber RS-274X, ODB++, IPC-2581, DXF |
Why Choose Our Layout Services
Professional PCB design expertise you can rely on.
Experienced Engineers
Our team of seasoned PCB designers has delivered thousands of successful designs across diverse industries including consumer electronics, automotive, medical, and aerospace.
Fast Turnaround
Standard layout projects completed in as fast as 2 business days. Rush services available for time-critical projects without sacrificing quality.
Comprehensive DFM
Every design undergoes thorough DFM, DRC, and ERC checks to ensure smooth manufacturing transition, reducing costly re-spins and production delays.
Ready to Start Your Project?
Send us your design files and let our team provide a competitive quote within 24 hours.
