Precision SMT Stencil Services
Professional SMT stencils with 12h build time. 304 HTA stainless steel with precision laser cutting for reliable solder paste deposition.
What is an SMT Stencil?
An SMT stencil is a precision stainless-steel template used to deposit solder paste onto a PCB during the surface mount assembly process. The stencil defines the exact amount and location of solder paste applied, ensuring accurate component placement and reliable solder joints.
Accurate Paste Deposition
Precision laser-cut apertures ensure the exact amount of solder paste is applied to each pad.
Consistent Quality
Uniform aperture geometry delivers repeatable paste volume for consistent assembly results.
Reduced Defects
Minimizes solder bridging, tombstoning, and insufficient solder issues that plague hand-soldering.
Stencil Types
Choose the right stencil type for your assembly needs.
By Frame Type
Non-Framework (Frameless)
Flexible, cost-effective stencils ideal for manual solder paste application and low-volume production.
- No frame required
- Lower cost
- Easy storage
- Hand-printing friendly
Framework (Framed)
Permanently mounted stencils designed for automated SMT printing machines and high-volume production lines.
- Machine-compatible
- Precise alignment
- Durable mounting
- High volume production
By Process / Treatment
Nano Coating
Advanced nano-particle coating for faster paste release and reduced solder bridging.
Electropolishing
Electrochemical smoothing of aperture walls for superior paste release and cleaner stencils.
Step Stencil
Varying thickness across the stencil to optimize paste volume for different component sizes on the same board.
Ultrasonic-Resistant Adhesive
Specially bonded stencils that withstand ultrasonic cleaning for extended lifespan and reuse.
Technical Specifications
Precision-engineered stencils built to the highest standards.
| Parameter | Specification |
|---|---|
| Material | 304 HTA Stainless Steel |
| Min Aperture | 0.08mm (supports 01005, 0.35mm BGA) |
| Cutting Tolerance | ±0.003mm |
| Max Stencil Size | 29" × 29" (736 × 736 mm) |
| Technology | Precision Laser Cutting |
| Thickness Options | 0.08mm – 0.3mm |
| Build Time | 12 hours (standard) |
| File Formats | Gerber, DXF, ODB++ |
Why Choose Our Stencils
Trusted by electronics manufacturers worldwide for quality and reliability.
Excellent Print Quality
Precision laser cutting with nano-coating options ensures accurate solder paste deposition and consistent print quality across every board.
Competitive Pricing & Fast Turnaround
Starting from just $3 with as fast as 12-hour build time. Volume discounts available for production orders.
Full Custom Support
Custom stencil designs including step stencils, multi-level apertures, and special coatings tailored to your unique requirements.
Ready to Start Your Project?
Send us your design files and let our team provide a competitive quote within 24 hours.
