Quick Turn PCB Assembly
24-hour prototype assembly and 48-hour standard quick turn. Quick turn PCB fabrication plus assembly under one roof — BGA, fine-pitch, and full AOI/X-Ray inspection on every expedited build.
Speed Without Compromised Inspection
Quick turn PCB assembly exists for the moments when waiting a week is not an option — design freezes, trade show demos, investor reviews, and urgent field-failure reproductions. But speed without inspection is just shipping defects faster.
Our quick turn lines run the same SPI, AOI and X-Ray process as standard builds. The difference is in logistics: on-hand material buffers, express DFM review, and fabrication-plus-assembly on one campus — so no board waits for a truck between suppliers.
- 24-hour prototype assembly on qualified designs
- Quick turn PCB fabrication from 24 hours
- Full BGA X-Ray inspection on every quick turn build
- Fabrication and assembly on the same campus
Quick Turn Service Tiers
Choose the turnaround that matches your project urgency.
24-Hour PCB Assembly
Expedited prototype builds for urgent design iterations. Same-day DFM review, next-day shipment on qualified designs.
48-Hour Quick Turn
Standard fast turn PCB assembly for engineering verification and small batch qualification runs with full inspection.
Quick Turn Fabrication
Fast bare board fabrication — quick turn PCB fabrication from 24 hours, ready for immediate assembly or standalone shipment.
Quick Turn Assembly Capabilities
Full technical envelope — no capability is reserved for standard lead times.
| Parameter | Capability |
|---|---|
| Fastest Turnaround | 24 hours for prototype assembly |
| Standard Quick Turn | 48 hours; 2–5 business days for complex builds |
| Quick Turn Fabrication | Bare boards from 24 hours, 1–24 layers |
| Assembly Types | SMT, THT and mixed technology; single- and double-sided |
| Smallest Component | 01005 (0.4 × 0.2 mm), 0201, 0402 and larger |
| Fine-Pitch & BGA | QFN, QFP, LGA, BGA down to 0.35 mm pitch |
| Supported Boards | FR-4, HDI, Flex, Rigid-Flex, Metal Core, High-Frequency, Hybrid |
| Inspection | SPI, AOI, X-Ray for BGA/QFN, flying probe and functional test |
| Component Sourcing | Turnkey sourcing from authorized distributors, including cut-tape |
Why Engineers Trust Our Quick Turn
Fast is only useful when the boards work.
True 24-Hour Capability
Quick turn PCB assembly is not just a label — it means a DFM review within hours, materials pulled from on-hand stock, and shipment within one business day on qualified designs.
Pre-Production DFM Check
Every quick turn order gets engineering review before the line starts, catching assembly risks while they are still cheap to fix — even on a 24-hour build.
Advanced Component Handling
Fine-pitch placement down to 01005 and 0.35 mm BGA, with nitrogen reflow and X-Ray inspection for hidden joints. Speed does not mean skipping capability.
Fab + Assembly Under One Roof
Quick turn PCB fabrication and assembly happen on the same campus — no waiting for boards to ship between suppliers before assembly can begin.
How Quick Turn Works
Four steps from files to shipped boards — compressed into hours, not days.
Upload Files
Send Gerber/ODB++, BOM and pick-and-place data through our RFQ form.
Express DFM Review
Engineers verify manufacturability and component availability within hours, not days.
Confirm & Schedule
Receive a quote with confirmed turnaround time — 24h, 48h, or standard.
Build, Inspect & Ship
Boards are assembled, inspected with AOI/X-Ray and shipped via express courier.
Related Services
Quick turn is often the first step — these services cover what comes next.
Quick Turn PCB Assembly FAQ
Common questions about turnaround, capabilities and process.
Prototype PCB assembly can ship in as fast as 24 hours when materials are in stock and the design passes DFM review. Standard quick turn PCB assembly takes 48 hours. More complex boards with hard-to-source components or advanced HDI construction may require 2–5 business days — we confirm the exact turnaround in your quote.
Quick turn PCB fabrication produces bare boards — the printed circuit board itself, without components. Quick turn PCB assembly takes bare boards (fabricated by us or supplied by you) and populates them with components through SMT, THT or mixed assembly. We offer both under one roof, which eliminates the transit delay between separate fab and assembly suppliers.
Yes. Our quick turn lines handle BGA down to 0.35 mm pitch, QFN, QFP, LGA and 01005 components. Every quick turn build with BGA or hidden-joint packages receives X-Ray inspection — speed does not reduce the inspection standard.
Both. Quick turn PCB fabrication starts from 24 hours for bare boards up to 24 layers, and quick turn assembly can begin immediately after fabrication on the same campus. You can order fabrication only, assembly only (with your supplied boards), or the combined fab-plus-assembly service.
Fast turn PCB assembly is another way buyers search for expedited assembly services — it refers to the same capability as quick turn. Whether you call it quick turn or fast turn, the service is the same: shortened lead times for prototype and small batch builds, with full inspection applied.
Yes. We fabricate and assemble HDI boards with laser microvias, Anylayer construction and blind/buried vias on quick turn schedules. HDI builds may take slightly longer than standard FR-4 due to sequential lamination cycles, but 48–72 hour turnaround is achievable on many HDI designs.
Provide Gerber (RS-274X) or ODB++ fabrication files, a BOM with manufacturer part numbers, and pick-and-place (centroid) data. For fabrication-only orders, just the Gerber files are needed. Our engineers can assist if any file is incomplete — but faster file submission means faster turnaround.
Need Boards Fast?
Upload your design files — get a quick turn quote with confirmed turnaround time within hours.
